Medical devices and diagnostic systems may be stored, transported and operated in very different climates. Portable devices can move between vehicles, clinics and homes, while laboratory analyzers may operate continuously with sensitive optics, fluids and electronics. Environmental testing helps verify that safety-related and performance functions remain within specification throughout those conditions.
The test plan should be risk-based. It must reflect the device’s intended use, transport route, packaging, operating state and the consequences of failure.
Separate storage, transport and operation
Storage limits can be wider than operating limits, and transport may include rapid changes that do not occur during normal use. Define each phase separately. A device may be unpowered during cold storage, then require a controlled recovery period before operation.
For portable equipment, consider condensation when a cold device enters a warm clinical environment. For reagent or fluid systems, verify whether viscosity, bubbles or phase changes influence performance.
Monitor critical functions
Powered tests should capture the parameters that support the device’s intended performance. These may include sensor accuracy, optical output, flow, pressure, battery capacity, alarms, communication and software status. Chamber data should be time-aligned with device logs so transient faults are not missed.
Use representative consumables and accessories when they affect thermal or humidity behavior.
Control contamination and access
Test chambers are environmental systems, not cleanrooms or biological containment devices unless specifically engineered for those functions. Define cleaning materials, sample restrictions and cross-contamination controls. If the device uses biological or chemical materials, complete an appropriate safety assessment before chamber use.
Cable and tubing feedthroughs should maintain chamber performance while allowing realistic operation. Door opening should be minimized and documented.
Include packaging when relevant
Packaging can moderate or amplify temperature and humidity exposure. If the objective is distribution validation, test the packaged device according to the approved sequence and allow it to reach the required conditioning state. ISO 11607-1:2019 defines requirements for sterile barrier and packaging systems for terminally sterilized medical devices, while other distribution and conditioning standards may apply.
Testing an unpackaged device answers a different question from testing the complete shipping configuration.
Build traceable evidence
IEC 60068 environmental methods may support medical-device development, but the governing requirements come from the device specification, risk-management process, regulatory plan and target market. Record specimen configuration, software version, accessories, sensor calibration and acceptance limits.
SCICOOLING provides benchtop, temperature-humidity and walk-in systems with configurable ports and monitoring for medical and diagnostic equipment. A useful program links every environmental exposure to a defined risk and every result to a measured device function.
